P355QL1 boiler zoo steel

Pressure Vessel Steel Plhaub Phaj Khoom Piav Qhia

P355QL1 steel boiler phaj yog European txheem tempered thawv phaj, P355QL1 boiler steel phaj Executive txheem: EN 10028-6: 2017.

Cov khoom ntawm P355QL1 boiler phaj yog alloy tshwj xeeb hlau nrog zoo plasticity, toughness, txias dabtsi yog khoov kev ua tau zoo thiab vuam kev ua tau zoo.

P355QL1 lub nkoj phaj tuaj yeem siv los ua cov khoom siv thiab cov khoom siv xws li reactor, heat exchanger, separator, ball tank, oil and gas tank.

Kub Rolled Pressure Vessel Steel Phaj Khoom Paub meej

P355QL1 Pressure Vessel Plate Chemical Composition & Mechanical Property:

C	Si	Mn	P	S	B	N	Cr
0.16	0.40	1.50	0.020	0.010	0.005	0.015	0.30
Cu	Mo	Nb	Ni	Ti	V	Zr
0.30	0.25	0.05	0.50	0.03	0.06	0.05

Thickness (hli)
P355QL 1	Tsawg dua los yog sib npaug li 50	>50 Tsawg dua los yog sib npaug rau 100	> 100
Yield zog (Ntau dua lossis sib npaug rau Mpa)	355	335	315
	Tsawg dua los yog sib npaug li 100		> 100
Tensile zog (Mpa)	490-630		450-590
