S355J2 H Beam Steel

Gnee Steel (Tianjin) Co., Ltd. yog ib qho ntawm cov kws tshaj lij s355j2 h beam steel tuam ntxhab thiab cov muag khoom hauv Suav teb, kuj txhawb kev pabcuam customized. Yog tias koj yuav mus yuav s355j2 h beam steel ua nyob rau hauv Suav teb, txais tos kom tau txais cov qauv dawb los ntawm peb lub hoobkas. Cov khoom zoo thiab tus nqi qis yog muaj.





S355J2 H nqajyog tus qauv European qis- alloy siab- lub zog steel seem tsim ua raws liTS EN 10025-2. Nrog rau qhov tsawg kawg nkaus tawm lub zog ntawm355 MPa rau, H-cov hlau profile no muaj cov khoom zoo heev-cov kabmob muaj peev xwm, weldability, thiab cov qauv kev ruaj ntseg rau kev xav tau cov haujlwm engineering.



Qhov tseem ceeb feature ntawmS355J2 hlauyog nwscuam ​​tshuam toughness ntawm -20 degree, uas ua kom ntseeg tau tias kev ua tau zoo hauv cov huab cua txias lossis cov qauv raug rau cov khoom siv dynamic. Qhov no ua rau S355J2 H beams yog qhov kev xaiv zoo tshaj plaws rau cov txuas hniav, cov qauv hlau hnyav, thiab cov phiaj xwm kev tsim kho uas muaj kev nyab xeeb thiab ruaj khov yog qhov tseem ceeb.



Raws li tus kws tshaj lij steel xa khoom, Gnee tuaj yeem muabS355J2 H profile steel kab teeb nyob rau hauv ntau qhov ntau thiab tsawg, customized lengths, thiab export -npaj ntim, pab cov neeg cog lus thoob ntiaj teb thiab cov neeg xa khoom kom tau txais qib siab -cov qauv hlau zoo.



S355J2 H Beam Steel Khoom Paub meej



H BEAM TAB
SIZE	Theoretical hnyav-GB(kg/m)	Theoretical hnyav-JIS(kg/m)	SIZE	Theoretical hnyav-GB(kg/m)	Theoretical hnyav-JIS(kg/m)
200*100*5.5*8	21.7	20.9	458*417*30*50	415	415
200*200*8*12	50.5	49.9	482*300*11*15	115	111
200*204*12*12	56.7	56.2	488*300*11*18	129	125
244*175*7*11	44.1	43.6	496*199*9*14	79.5	77.9
248*124*5*8	25.8	25.1	498*432*45*70	605	604
250*125*6*9	29.7	29	500*200*10*16	89.6	88.1
250*250*9*14	72.4	71.8	506*201*11*19	103	102
250*255*14*14	82.2	81.6	582*300*12*17	137	133
294*200*8*12	57.3	55.8	588*300*12*20	151	147
294*302*12*12	85	83.5	594*302*14*23	175	170
298*149*5.5*8	32.6	32	596*199*10*15	95.1	92.4



Mechanical Properties ntawm S355J2 H Beam



Khoom	Tus nqi
Yield zog	Ntau dua lossis sib npaug li 355 MPa
Tensile zog	470-630 MPa
Impact Test	27J ntawm -20 degree
Txuj	TS EN 10025-2
Weldability	Zoo heev



Muaj Qhov Loj ntawm S355J2 H Profile Steel



Peb muab kub- dov H beams nyob rau hauv ntau yam ntawm cov qauv thiab customized qhov ntev.

Parameter	Ntau yam
Qhov siab (H)	100-900 hli
Flange dav (B)	100-300 hli
Web Thickness	5-16 hli
Flange Thickness	8-32 hli
Ntev	6 m / 9 m / 12 m lossis customized

Cov kev xaiv ntawm qhov chaw muaj xws li cov hlau dub tiav, txhaj tshuaj- blasted nto, lossis galvanized ua raws li qhov yuav tsum tau ua.



S355J2 H Beam Structural Steel Khoom Duab



S355J2 H profile steel yog dav siv nyob rau hauv cov qauv kev ua haujlwm uas yuav tsum tau muaj zog load-cov kabmob muaj peev xwm thiab txhim khu kev qha hauv cov cheeb tsam hnyav.

1. Cov qauv tsim rau cov tsev hlau

S355J2 H beams feem ntau yog siv los ua thawj cov khoom thauj -cov kabmob kab thiab kab teeb hauv steel qauv vaj tse xws li cov chaw tsim khoom, tsev khaws khoom, thiab cov chaw lag luam.

Piv nrog rau cov qauv hlau zoo tib yam, lub zog muaj zog ntau dua ntawm S355J2 tso cai rau cov kws ua haujlwm kom txo cov khoom hnyav thaum tuav lub zog, txhim kho cov khoom siv tau zoo thiab txo cov nqi tsim kho tag nrho.



2. Kev tsim kho choj

Hauv kev tsim choj choj, S355J2 H kab teeb yog siv rau lub ntsiab girders, hla kab, thiab cov qauv kev txhawb nqa.

Vim tias qib steel muaj xws li J2 qhov kev ntsuam xyuas ntawm -20 degree, nws ua tau zoo nyob rau hauv dynamic loads, vibration, thiab kub-kub ib puag ncig, ua rau nws haum rau txoj kev loj choj, railway choj, thiab overpasses.



3. Offshore thiab Marine Structures

S355J2 H profile steel kuj tau siv dav hauv cov chaw nres nkoj, cov chaw sab nrauv, thiab cov chaw ntug dej hiav txwv.

Nws lub zog siab thiab cov qauv kev ruaj ntseg pab kom ntseeg tau tias cov khoom siv hlau tuaj yeem tiv taus cua loads, yoj cuam tshuam, thiab ntev - lub sij hawm txhua yam kev ntxhov siab, uas muaj ntau nyob rau hauv marine ib puag ncig.



4. Heavy Machinery thiab Cov Khoom Siv Ua Haujlwm

Rau cov tshuab loj loj, cranes, thiab cov khoom siv hnyav, S355J2 H beams muab cov qauv kev txhawb zog muaj peev xwm los tuav cov khoom tseem ceeb.

Qhov zoo weldability ntawm qib steel no ua rau nws yooj yim dua rau cov tuam ntxhab los tsim cov txheej txheem welded nyuaj, txhim kho kev tsim khoom.



5. Cov phiaj xwm hluav taws xob thiab kev tsim vaj tsev

S355J2 H kab teeb yog nquag siv hauv cov chaw tsim hluav taws xob, cov chaw siv hluav taws xob cua, thiab cov phiaj xwm loj.

Lawv lub zog thiab kev ntseeg tau ua kom ruaj khov hauv cov qauv xws li:

• fais fab nroj tsuag steel ncej
• cua turbine txhawb cov qauv
• kev thauj mus los infrastructure
• cov nroj tsuag muaj





Txoj kev xa khoom	Kev piav qhia
Hiav txwv Freight (Container Shipping)	Txoj kev xa khoom tshaj plaws rau kev txiav txim thoob ntiaj teb. Cov khoom siv hlau yog thauj mus rau hauv20ft los yog 40ftntim nrog cov qauv seaworthy packing kom muaj kev nyab xeeb kev thauj mus los thaum lub sij hawm ntev - shipping.
Bulk Vessel Shipping	Haum rauloj - ntim steel xaj, xws li H beams, daim hlau, lossis rails. Cargo yog xa los ntawmcov nqa khoom loj, uas tuaj yeem txo cov nqi thauj khoom rau cov haujlwm loj.
FOB / CIF / CFR Cov Cai	Peb txhawb kev lag luam thoob ntiaj teb cov ntsiab lus xws liFOB, CIF, thiab CFR, cia cov neeg siv khoom xaiv qhov yooj yim tshaj plaws logistics kev npaj.
Export Ntim	Tag nrho cov khoom yog ntim nrogtxheem export seaworthy ntim, nrog rau cov hlua khi hlau, kev tiv thaiv qhwv, thiab cov khoom siv ntxiv los tiv thaiv kev puas tsuaj thaum thauj.
Export Cov ntaub ntawv	Peb muab tag nrho cov ntaub ntawv xa tawm suav nrogMill Test Certificate (MTC), Commercial Invoice, Packing List, Certificate of Origin, thiab lwm yam ntaub ntawv xav tau rau kev lis kev cai clearance.
Custom Logistics Support	Peb pab neeg tuaj yeem pab nrogchaw nres nkoj booking, kev lis kev cai tshaj tawm, thiab thoob ntiaj teb freight npajkom ntseeg tau tias kev xa khoom zoo mus rau koj qhov chaw nres nkoj.
Project Cargo Shipping	Rau cov haujlwm loj engineering, peb tuaj yeem npajtawg bulk shipping lossis project cargo logisticsrau cov qauv hlau loj thiab ntev - ntev kab.



Peb muab kev xaiv xa khoom yooj yim nyob ntawm qhov hnyav, qhov loj me, thiab qhov ntau ntawm koj qhov kev txiav txim.









Hu rau tam sim no kom tau txais S355J2 H Beam Quote
